Chicken House Central Air Source Heat Pump Green And Environmental Protection

Product Categories

Shandong Yushen Energy Technology Co., Ltd.

Contact Now

Name: Chicken House Central Air Source Heat Pump Green And Environmental Protection
Brand: Yushen
Price: 1 USD

Brand Name : Yushen

Model Number : SLNC-075Y

Certification : CCC, ISO, CQC

Place of Origin : China

MOQ : 1 set

Price : negotiable

Payment Terms : T/T

Supply Ability : 10 sets/day

Delivery Time : 1-2weeks

Packaging Details : Reinforced Carton box with wooden tray

Name : Chicken house Air Source Heat Pump

Compressor capacity : 25HP

Service area : 800~1000 sqm per set

Function : cooling and heating

Overall size : 2100×1100×2080mm

Application : Chicken House

Contact Now

Chicken House Central Air Source Heat Pump Green And Environmental Protection

Central Air Source Heat Pump Advantages

Larger application range , yushen heat pump could be used from environmental temperature:-25℃ to +45 ℃ /or from -13℉ to 113 ℉
100% finished products testing,quality Components such as Copeland compressor, Danfoss valves
35% more powerful than other products,yushen air-source heat pump has longer heating time and shorter defrosting time
High COP, No capacity decay even under low environmental temperature

Central Air Source Heat Pump information

Multi-function---Configure multi-function units for heating, cooling and hot water according to user needs.
Green and environmental protection---It will not discharge waste heat, waste water, waste gas and other harmful substances indoors or outdoors, and it is absolutely environmentally friendly.
Significant energy saving --- energy efficiency can reach 4 times of electric heating, operating cost is only 1/4 of electric boiler, 1/3~1/2 of gas-fired boiler, not only saves a lot of electric energy, but also saves operating costs.

Central Air Source Heat Pump Parameter

Model				SLNC-075Y Central Air Source Heat Pump code name.pdf
Compressor capacity				25HP
Function				Heating and Cooling
Electricity				380V-3N-50Hz
Working conditions			℃	-25~+45
Data	Heat^a	Nominal capacity	KW	44.5
		Input power	KW	18.3
		COP	/	2.4
	Heating IPLV(H)			2.7
	Cool^b	Nominal capacity	KW	62
		Input power	KW	20.7
		COP	/	3
	Cooling IPLV(C)			2.7
	A7W35c		KW/COP	75.0/4.2
	A2W35		KW/COP	62.5/3.20
	A-7W35		KW/COP	50/2.9
	A-15W55		KW/COP	45.5 /1.97
	A-20W45		KW/COP	37.4/2.04
Max. running currency			A	56
Compressor quantity			set	2
Refrigerant/charging quantity kg			/	R22/15*2
Air blow type			/	Top
Water pipe diameter			mm	50
Rating flow			m³/h	12.6
Water side pressure loss			kPa	≤45
Noise level			dB(A)	62
Overall dimensions(L×W×H)			mm	2100×1100×2080
Weight			kg	730

A7W35 working condition: inlet air temperature 7℃, outlet water temperature 35℃

a: Nominal heating conditions: ambient dry bulb temperature-12℃, wet bulb temperature-14℃, outlet water temperature 41℃, water flow 0.172 * nominal
